Description
Technical data
- Special core insulation made of PVC
- Temperature resistance: (3000 h) -40°C to 105°C
- Operating voltage: up to 60 V
- Test voltage: 1 kV (effective value)
- Breakdown voltage: 5 kV (rms) Volume resistivity: min. 109 Ohm · mm
Structure
- Bare copper conductor, soft-annealed electrolytic copper E-Cu58 F21 to DIN 40500 Part 4 (The mechanical requirements apply to the unprocessed single wire.)
- Bare copper stranded wire, conductor construction according to DIN 72551 Part 6
Type B: asymmetrical conductor construction
- Special core insulation made of PVC
Properties
- Oil and fuel resistant according to DIN ISO 6722 Part 2
- Special properties Space and weight saving due to reduced insulation wall thickness
- Requirements and tests according to DIN 72551 Part 5
